Prestige 128MH PSTN Router/Hub
1-2 Chapter 1 Getting to Know Your Router/Hub
1.2 Front Panel LEDs and Back Panel Ports
1.2.1 Prestige 128MH Front Panel
À :
PWR = Power LED
Á :
TST = Test LED (Blinking)
 :
ETHERNET (1, 2, 3, 4) = 4-PORT 10Base-T HUB (Active Ethernet Port #)
à :
WAN = WAN port 1 Ready, Transmit/Receive
Ä :
MODEM-1 (RDY, TX/RX) = Internal Modem-1 (on WAN port 2) Ready, Transmit/Receive
Å :
MODEM-2 (RDY, TX/RX) = Internal Modem-2 (on WAN port 3) Ready, Transmit/Receive
Figure 1-1. Prestige 128MH Front Panel LEDs
А Б Д Е В Г
PWR TST RDY TX/RX RDY TX/RX WAN
MODEM-1 MODEM-2 ETHERNET
1 2 3 4
Prestige 128MH
PSTN Router/Hub
