Prestige 128MH PSTN Router/Hub
9-4 Chapter 9 Filter Configuration
Step 4. Once you press [Enter] to confirm your changes, Menu 21.1 - Filter Rules Summary
appears.
Filter Rules Summary Menu
The information displayed in the Menu 21.1 - Filter Rules Summary is read-only. From here, you
can examine the parameters of each rule that you have configured for that filter set.
Figure 9-3 displays Menu 21.1 - Filter Rules Summary.
Figure 9-3. Menu 21.1 - Filter Rules Summary
The following Table 9-1 contains a brief description of the abbreviations used in Menu 21.1.
Table 9-1. Abbreviations Used in the Filter Rules Summary Menu
Abbreviations Description Display
# Refers to the filter rule number (1-6).
A Refers to Active. [Y] means the filter rule is active.
[N] means the filter rule is inactive.
Type Refers to the type of filter rule.
This can display GEN for generic, IP for
TCP/IP, or IPX for Novell IPX.
[GEN] for Generic
[IP] for TCP/IP
[IPX] for Novell IPX
Menu 21.1 - Filter Rules Summary
# A Type Filter Rules M m n
- - ---- --------------------------------------------------------------- -
- -
1 N
2 N
3 N
4 N
5 N
6 N
Enter Filter Rule Number (1-6) to Configure:
