Prestige 128MH PSTN Router/Hub
1-3 Chapter 1 Getting to Know Your Router/Hub
1.2.2 Front Panel LEDS
The LED indicator lights on the front panel of your Prestige indicate the Router/Hub functional
status. The following Table 1-1 describes the LED functions:
Table 1-1. LED Functions
LEDs Function Indicator
Status Active Description
PWR Power LED Green On The power AC adapter is connected to the Prestige.
TST Test LED Green Blinking The Prestige is functioning properly.
Ready Green On The modem or IDSN TA connected to WAN port 1 is in
use. WAN
(WAN 1)
Transmit/Receive Green Blinking Traffic is being transmitted or received on WAN port 1.
On The Prestige has successfully connected to LAN port
1,2,3,4 via the UTP Ethernet interface. ETHER-
NET 1,2,3,4 LAN Transmit
LAN Receive
Green
Blinking Traffic is being transmitted/received on LAN port 1,2,3,4,
RDY Ready Green On The internal modem connected to WAN port 2 is in use. MODEM-1
(WAN 2)
TX/RX Transmit/Receive Green Blinking Traffic is being transmitted or received on WAN port 2.
RDY Ready Green On The internal modem connected to WAN port 3 is in use. MODEM-2
(WAN 3)
TX/RX Transmit/Receive Green Blinking Traffic is being transmitted or received on WAN port 3.
