Prestige 128MH PSTN Router/Hub
2-16 Chapter 2 Hardware Installation & Initial Setup
l Figure 2-9b displays Menu 2.1 when configuring WAN port 2 and 3 internally
connected to the built-in 56K modem LINE 1 and LINE 2 respectively.
Figure 2-9b. Menu 2.1 - Async WAN Port Setup for WAN Port 1,2 (LINE 1,2)
Table 2-5 describes how to configure the WAN port 1 with the external modem or ISDN TA
parameters, and WAN port 2 and 3 with the internal 56K modem line parameters.
Table 2-5. Async WAN Port Setup Menu Fields
Field Description Example
Modem Name Enter a descriptive name for the Modem or ISDN TA connected to this
WAN Port. ZyXEL
Active Set to [Yes] to activate a WAN port, then your Prestige will initialize the
WAN Port and the attached Modem or ISDN TA. When a WAN Port is
deactivated, it has no effect on the operation of your Prestige, even
though its profile is still kept in the database, and can be activated in the
future. Press space-bar
to toggle
[Yes/No]
Connection
Type For WAN Port 1 (Serial WAN port connected to external modem or
ISDN TA), select the connection type for your particular application.
Select [Switch] for Dial-up application or [Leased] for Leased Line
Modem application. Press space-bar
to toggle
[Switch/Leased]
Menu 2.1 - Async WAN Port Setup
Modem Name= ZyXEL
Active= Yes
Connection Type= Switch (r.o.)
Phone Number=
Device Type= 56K Modem (r.o.)
Port Speed= 115200
AT Command String:
Init=ats0=0W2&fs95=1
Advanced Setup= No
Press ENTER to Confirm or ESC to Cancel:
