Status Registers and Result Codes 145
Command bit dec hex Function and description Ref.
S127= 0-
255 0-
FF Sub-threshold for BOD in Kbps
unit JSn,+32
S128= bit dec hex For DTE port 2 only.
0
*0 0 Two POTS and one DTE port.
1 1 One POTS and two DTE ports
•
Bit - S-register bit number, 'b', used in 'ATSr.b=n' and 'ATSr.b=?'
•
dec - Decimal value, 'x', used in 'ATSn=x'
•
hex - Equivalent Hexadecimal value.
•
+nnn - Factory default when listed in 'Reference' column.
"ATXn" Result Code Option Table
The following table shows the different options available when
setting the ATXn command. The default value for ‘n’ is 5 when the
omni is shipped:
ATV0 ATV1 X0 X1 X2 X3 X4 X5 X6 X7
0 OK V V V V V V V V
1 CONNECT V V V V V @ $ #
2 RING V V V V V V V V
3 NO CARRIER V V V V V V V V
4 ERROR V V V V V V V V
5 CONNECT 1200 % % % % @ $ #
6 NO DIAL TONE V V V V V
7 BUSY V V V V V
8 NO ANSWER V V V V V
9 RINGING* V V V V V
10 CONNECT 2400 % % % % @ $ #
11 CONNECT 4800 % % % % @ $ #
12 CONNECT 9600 % % % % @ $ #
14 CONNECT 19200 % % % % @ $ #
15 CONNECT 7200 % % % % @ $ #
16 CONNECT 12000 % % % % @ $ #
