100 Diagnostics
15
Diagnostics
The omni can perform its own diagnostic tests, providing you with
valuable information. This chapter provides diagnostic tables for
interpreting test results.
The following table is a summary of the omni's self-tests for external
models:
Test
Seq. LED
LNK LED
B1 LED
B2 LED
AA Test Description
1 on* off off off Memory test.
2 off on* off off ISDN chip interface test.
3 off off on* off ISDN chip functional test.
4 off off off on* HDLC functional test.
* The LED lights up while test is in progress and blinks if a test fails.
The following table is a summary of the omni's self-tests for internal
models:
Blinks Test Description
1 Memory test failed.
2 ISDN chip interface test failed.
3 ISDN chip functional test failed.
4 HDLC functional test failed.
O NOTE
: When a self test fails the LED will blink 1-4 times in succession,
followed by a 1.5 second pause. After completing a successful
self test the LED will remain off.
Diagnostics
The omni ISDN TA provides several diagnostic capabilities:
•
Power-on Self-test.
•
Local Digital Loopback Test.
