Chapter 9 Status Screens
V500 Series User’s Guide
171
Registration This field displays the current registration status of the SIP account. You can
change this in the Status screen.
Registered - The SIP account is registered with a SIP server.
Unregister - The SIP account has failed to register with a SIP server, or is not
active.
Last
Registration This field displays the last time you successfully registered the SIP account. It
displays N/A if you never successfully registered this account.
URI This field displays the account number and service domain of the SIP account.
You can change these in VoIP > SIP > SIP Settings.
Protocol This field displays the transport protocol the SIP account uses. SIP accounts
always use UDP.
Message
Waiting This field indicates whether or not there are any messages waiting for the SIP
account.
Last Incoming
Number This field displays the last number that called the SIP account. It displays N/A if no
number has ever dialed the SIP account.
Last Outgoing
Number This field displays the last number the SIP account called. It displays N/A if the
SIP account has never dialed a number.
Call Statistics
Call This field displays the V500’s line number.
Status This field indicates whether the line is active or not.
Idle - The line is not active.
Dial - the line is active and a connection to a SIP server has been made, but a call
is not in progress.
Dialing - the V500 is initiating a call on this line.
Ringing - the V500 has initiated a call, and the phone at the other end is ringing.
Connected - a call is in progress on this line.
Disconnect - the line is active, but the connection with the SIP server has been
terminated.
Hold - a call on this line is on hold.
Waiting - another line is active, and this line has an incoming call that has not
been answered.
Transfer - a call on this line is waiting to be transferred.
Transferred - a call on this line has been transferred to another number, and is
still ongoing.
Incoming - an incoming call on this line is waiting to be answered.
Busy - the V500 has tried to initiate a call, but the phone at the other end is
engaged.
Codec This field displays what voice codec (coder/decoder) is being used for a current
VoIP call.
Peer Number This field displays the SIP number of the person on the other end of the line, when
a call is in progress.
Duration This field displays how long the current call has lasted.
Packets Sent This field displays the number of packets the V500 has transmitted in the current
call.
Packets Recv This field displays the number of packets the V500 has received in the current call.
Tx B/s This field displays how quickly the V500 has transmitted packets in the current
call. The rate is the average number of bytes transmitted per second.
Rx B/s This field displays how quickly the V500 has received packets in the current call.
The rate is the average number of bytes transmitted per second.
Table 102 VoIP Statistics
LABEL DESCRIPTION
