Chapter 9 Status Screens
V500 Series User’s Guide
170
9.4 VoIP Statistics
This screen displays SIP registration information, status of calls and VoIP traffic statistics. To
access this screen, open the Status screen (see
Section 9.2 on page 167 ), and click (Details...)
next to VoIP Statistics.
Figure 128 VoIP Statistics
Each field is described in the following table.
RxPkts This field displays the number of packets received on this interface.
Collisions This field displays the number of collisions on this port.
Tx B/s This field displays the number of bytes transmitted in the last second.
Rx B/s This field displays the number of bytes received in the last second.
Up Time This field displays the elapsed time this interface has been connected.
System up Time This is the elapsed time the system has been on.
Poll Interval(s) Type the time interval (in seconds) for the browser to refresh system statistics.
Set Interval Click this button to apply the new poll interval you entered in the Poll Interval
field.
Stop Click this button to halt the refreshing of the system statistics.
Table 101 Packet Statistics (continued)
LABEL DESCRIPTION
Table 102 VoIP Statistics
LABEL DESCRIPTION
SIP Status
Account This column displays each SIP account in the V500.
