9.3 Packet Statistics
To access this screen, open the Status screen (see
), and click
(Details...) next to Packet Statistics. Read-only information here includes port status and
packet specific statistics. Also provided are "system up time" and "poll interval(s)". The Poll
Interval(s) field is configurable.
Figure 127 Packet Statistics
The following table describes the fields in this screen.
Registration
This field displays the current registration status of the SIP account. You have
to register SIP accounts with a SIP server to use VoIP.
If the SIP account is already registered with the SIP server,
Click Unregister to delete the SIP account’s registration in the SIP server.
This does not cancel your SIP account, but it deletes the mapping between
your SIP identity and your IP address or domain name.
The second field displays Registered.
If the SIP account is not registered with the SIP server,
Click Register to have the V500 attempt to register the SIP account with
the SIP server.
The second field displays Unregister.
URI
This field displays the account number and service domain of the SIP account.
You can change these in VoIP > SIP > SIP Settings.
Summary
VoIP Statistics
Click this link to view statistics about your VoIP usage.
Packet Statistics
Click this link to view port status and packet specific statistics.
Table 100 Status Screen
LABEL
DESCRIPTION
Table 101 Packet Statistics
LABEL
DESCRIPTION
Packet Statistics
Port
This column displays each interface of the V500.
Status
This displays the port speed and duplex setting.
TxPkts
This field displays the number of packets transmitted on this interface.
