1.
Go to Interfaces > Ethernet > Edit (lan)
2.
Now enter:
•
IP Address: 10.0.0.1
•
Network: 10.0.0.0/24
•
Transparent Mode: Disable
•
Add route for interface network: Disable
3.
Click OK
4.
Go to Interfaces > Ethernet > Edit (dmz)
5.
Now enter:
•
IP Address: 10.0.0.2
•
Network: 10.0.0.0/24
•
Transparent Mode: Disable
•
Add route for interface network: Disable
6.
Click OK
Configure the interface groups:
1.
Go to Interfaces > Interface Groups > Add > InterfaceGroup
2.
Now enter:
•
Name: TransparentGroup
•
Security/Transport Equivalent: Disable
•
Interfaces: Select lan and dmz
3.
Click OK
Configure the routing:
1.
Go to Routing > Main Routing Table > Add > SwitchRoute
2.
Now enter:
•
Switched Interfaces: TransparentGroup
•
Network: 10.0.0.0/24
•
Metric: 0
3.
Click OK
Configure the rules:
1.
Go to Rules > IP Rules > Add > IPRule
2.
Now enter:
•
Name: HTTP-LAN-to-DMZ
•
Action: Allow
•
Service: http
•
Source Interface: lan
•
Destination Interface: dmz
•
Source Network: 10.0.0.0/24
•
Destination Network: 10.1.4.10
