Page 117
•
Name: A suitable name for the rule, eg. Reports_if1
•
Type: Report
•
Action: Proxy
•
Output: wan (this is the relay interface)
3.
Under Address Filter enter:
•
Source Interface: if1
•
Source Network: if1net
•
Destination Interface: core
•
Destination Network: auto
•
Multicast Source: 192.168.10.1
•
Multicast Group: 239.192.10.0/24
4.
Click OK
B. Create the second IGMP Rule:
1.
Again go to Routing > IGMP > IGMP Rules > Add > IGMP Rule
2.
Under General enter:
•
Name: A suitable name for the rule, eg. Queries_if1
•
Type: Query
•
Action: Proxy
•
Output: if1 (this is the relay interface)
3.
Under Address Filter enter:
•
Source Interface: wan
•
Source Network: UpstreamRouterIp
•
Destination Interface: core
•
Destination Network: auto
•
Multicast Source: 192.168.10.1
•
Multicast Group: 239.192.10.0/24
4.
Click OK
Example 4.12. Configuration if2 - Group Translation
The following steps needs to be executed to create the report and query rule pair for if2 which translates the
multicast group. Note that the group translated therefore the IGMP reports include the translated IP addresses
and the queries will contain the original IP addresses.
Web Interface
A. Create the first IGMP Rule.
1.
Go to Routing > IGMP > IGMP Rules > Add > IGMP Rule
2.
Under General enter:
•
Name: A suitable name for the rule, eg. Reports_if2
4.5.3. IGMP Configuration
