UNT-IOM-6

49

Tracer

®

ZN.010

and ZN.510

Table 13. Test Sequence for 1-Heat /1-Cool Configurations
Steps

Fan

Cool Output

Heat Output

Damper

BOP1-3

BOP4 (1)

BOP5BOP6

1. Off

Off

Off

Off

Closed

2. Fan High

High

Off

Off

Closed

3. Fan Medium

Medium Off

Off

Closed

4. Fan Low

Low Off

Off

Closed

5. Cool

High On

Off

Closed

6. Heat

High Off

On

Closed

7. Fresh Air

High Off

Off

Open

Damper (3)

8. Exit

(2)

Notes:

(1) At the beginning of step 2, the controller attempts to clear all diagnostics.

(2) For all 1-heat/1-cool applications including 2-pipe changeover, BOP4 energizes in the cooling test

stage and BOP5 energizes in the heat test stage.This occurs even though during normal 2-pipe

changeover operation BOP4 controls the unit valve for both cooling and heating.

(2) After the Fresh Air Damper step, the test sequence performs the Exit step.This initiates a reset and

attempts to return the controller to normal operation.

(3) The fresh air damper (BOP6) only energizes during this step if binary output 6 has been configured as

a fresh air damper.
