75

SS-PRC003-EN

Weights

Vertical

TWE050, 075, 100

Vertical

TWE155, 200

Horizontal

TWE155, 200

Horizontal

TWE050, 075, 100

Table W-3 — Air Handlers and Corner Weights — lb

1

(kg)

Unit

Shipping

Net

Corner Weights — Vertical

Corner Weights — Horizontal

Model No.

Maximum

Maximum

1

2

3

4

A

B

C

D

TWE050A

298 (135.2)

232 (105.2)

59 (26.8)

59 (26.8)

59 (26.8)

59 (26.8)

54 (24.5)

64 (29.0)

64 (29.0)

54 (24.5)

TWE075A

388 (176.0)

317 (143.8)

79 (35.8)

79 (35.8)

79 (35.8)

79 (35.8)

73 (33.1)

81 (36.7)

84 (38.1)

77 (34.9)

TWE100A
TWE100B

439 (199.1)

392 (177.8)

98 (44.5)

98 (44.5)

98 (44.5)

98 (44.5)

95 (43.1)

101 (45.8)

101 (45.8)

95 (43.1)

TWE155B

754 (342.0)

692 (313.9)

173 (78.5) 173 (78.5) 173 (78.5) 173 (78.5)

156 (70.8)

174 (78.9)

190 (86.2)

170 (77.1)

TWE200B

886

816

204 (92.5)

204 (92.5)

204 (92.5)

204 (92.5)

179 (81.2) 221 (100.2) 228 (103.4) 185 (83.9)

TWE200E

857 (390)

787 (357)

109 (50)

262 (119)

154 (70)

262 (119)

192 (87)

229 (104)

130 (59)

236 (107)

NOTE:
1. If application requires steam or hot water heating coils, field supplied isolators must be utilized.

Table W-4 — Accessory Weights — Net Lbs (kg)

RIS

RIS

Discharge

Discharge

Discharge

Electric

Isolator

Isolator

Unit

Plenum

Plenum

Plenum

Return

Heat

Oversized

Floor

Suspended

Model No.

And Grille

1

And Grille

2

And Grill

3

Air Grille

Min./Max.

Subbase

Motor

Mount

Mount

TWE050A

63 (28.6)

58 (26.3)

93 (42.2)

3 (1.4)

32/43 (14.5/19.5)

14 (6.4)

31 (14.1)

2 (.91)

9 (4.1)

TWE075A

78 (35.4)

73 (33.1)

123 (55.8)

5 (2.3)

27/45 (12.2/20.4)

19 (8.6)

48 (21.8)

2 (.91)

6 (2.7)

TWE100A
TWE100B

97 (44.0)

92 (41.7)

156 (70.8)

7 (3.2)

27/45 (12.2/20.4)

23 (10.4)

50 (22.7)

2 (.91)

7 (3.2)

TWE155B

124 (56.2)

230 (104.3)

10 (4.5)

79/100 (35.8/45.4)

27 (12.2)

80 (36.3)

2 (.91)

7 (3.2)

TWE200B, E

145 (65.8)

264 (119.8)

12 (5.4)

79/100 (35.8/45.4)

31 (14.1)

88 (39.9)

2 (.91)

9 (4.1)

NOTES:
1. For use when no heat is supplied.
2. For use with electric heat.
