66

SS-PRC003-EN

Figure DD-9 — TWE050A Air Handlers

All dimensions are in inches and millimeters.

Dimensional
Data

Table DD-1 — Air Handler Dimensions — in. (mm)

Model No.

A

B

C

D

E

F

G

H

TWE050A

48

38

22

8

19-1/2

26

15-7/8

14-1/8

(1219.20)

(965.20)

(558.80)

(203.20)

(495.30)

(660.40)

(403.23)

(358.78)

Table DD-1 — (Continued)

Model No.

J

K

Q

S

V

W

Y

AA

TWE050A

1-7/8

42-1/8

34-5/8

3/8

1-1/8

1-7/8

(47.63)

(1069.98)

(879.48)

(9.53)

(28.58)

(47.63)
