Table PD-16
_
Gross Cooling Capacities (kW) - TTA200F w/ TWE200E - (SI)
Enter.
Dry
Bulb
m
3
/h
Temp
Airflow
(C)
MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
24
60.2 49.8 65.8 35.8 71.9 20.9 57.4 48.6 62.8 34.5 68.6 19.7 54.4 47.3 59.5 33.2 65.0 18.6 51.1 45.9 55.8 31.8 60.8 16.8
27
60.8 60.1 66.2 46.0 72.3 31.2 58.1 58.0 63.2 44.8 69.0 30.1 55.3 55.1 59.8 43.5 65.3 28.9 52.0 51.9 56.2 42.2 61.2 27.7
30
62.0 61.8 66.6 56.3 72.6 41.7 59.8 59.5 63.7 55.2 69.3 40.5 57.2 57.1 60.3 54.0 65.7 39.2 54.3 54.2 56.7 52.7 61.6 37.8
33
65.2 65.1 67.4 66.8 73.0 51.9 62.8 62.7 64.5 64.2 69.7 50.9 60.2 60.1 61.3 61.3 66.0 49.7 57.2 57.1 57.5 57.4 62.0 48.6
24
61.6 53.0 67.3 37.5 73.4 21.0 58.8 51.8 64.1 36.2 69.8 19.6 55.7 50.4 60.7 34.9 66.1 18.5 52.3 49.0 56.9 33.4 61.8 17.3
27
62.5 62.4 67.7 48.8 73.7 32.5 59.8 59.8 64.6 47.6 70.3 31.3 56.6 56.6 61.1 46.3 66.5 30.1 53.2 53.0 57.3 45.0 62.2 28.9
30
64.3 64.2 68.2 60.4 74.2 44.2 61.9 61.8 65.1 59.2 70.7 42.9 59.2 58.9 61.7 58.0 66.9 41.7 56.1 56.0 57.9 56.6 62.7 40.5
33
67.6 67.4 69.2 69.2 74.5 55.6 65.1 65.1 66.2 65.9 71.1 54.6 62.3 62.1 62.5 62.4 67.4 53.5 59.1 58.9 59.2 58.9 63.2 52.3
24
62.9 56.1 68.5 39.1 74.6 20.9 60.0 54.9 65.3 37.8 71.0 20.0 56.8 53.5 61.7 36.4 67.1 18.9 53.3 52.0 57.7 34.6 62.7 17.3
27
64.1 63.9 68.9 51.6 74.9 33.7 61.0 61.0 65.7 50.4 71.4 32.6 57.7 57.4 62.2 49.2 67.5 31.4 54.6 54.5 58.3 47.9 63.1 30.0
30
66.3 66.2 69.6 64.3 75.4 46.4 63.7 63.6 66.4 63.2 71.9 45.4 60.9 60.7 62.9 61.9 68.0 44.2 57.7 57.4 59.1 58.9 63.6 43.1
33
69.7 69.5 70.7 70.6 75.9 59.3 67.1 66.8 67.3 67.1 72.4 58.3 64.1 63.9 64.2 64.2 68.5 57.2 60.8 60.7 60.9 60.7 64.2 56.1
24
64.1 59.2 69.5 40.7 75.6 21.4 61.0 57.9 66.2 39.5 72.0 20.0 57.7 56.5 62.6 38.2 67.9 18.8 54.2 53.9 58.5 36.7 63.5 17.5
27
64.9 64.8 70.1 54.4 76.1 35.0 62.0 61.8 66.8 53.3 72.5 34.0 59.1 58.9 63.2 52.1 68.3 32.9 56.0 55.7 59.2 50.8 63.9 31.5
30
68.1 68.0 70.9 68.2 76.6 49.1 65.4 65.4 67.6 67.0 72.9 47.9 62.4 62.4 64.0 63.9 68.9 46.8 59.1 58.9 60.2 60.1 64.5 45.6
33
71.6 71.5 71.7 71.5 77.1 63.0 68.9 68.6 68.9 68.9 73.5 62.0 65.8 65.6 65.8 65.6 69.5 60.9 62.3 62.1 62.3 62.1 65.1 59.8
NOTES:
1. All capacities show n are gross and have not considered indoor fan heat. To obtain net cooling, subtract indoor fan heat.
2. MBH = Total Gross Capacity
3. SHC = Sensible Heat Capacity
Ambient Temperature (C)
Entering Wet Bulb Temperature (C)
11341
12488
10194
45
16
19
22
19
40
22
19
22
16
19
22
16
13634
30
35
16
