Page 70
70
SS-PRC003-EN
Dimensional
Data
Figure DD-13 — TWE155B and 200B Air Handlers
All dimensions are in inches and millimeters.
PANEL
Table DD-4— Air Handler Dimensions — in. (mm)
Model No.
A
B
C
D
E
F
G
H
J
K
TWE155B
69
79-1/2
27-5/8
12-3/8
1-5/8
26
25-1/8
49-1/8
56-1/4
15-1/2
(1752.60) (2019.30)
(701.68)
(314.33)
(41.28)
(660.40)
(638.18)
(1247.78)
(1428.75)
(393.70)
TWE200B
71-7/8
92-1/2
30-1/2
18-7/8
4-1/2
31
28
51-7/8
59-1/8
18-1/8
(1825.63) (2349.50)
(774.70)
(479.43)
(114.30)
(787.40)
(711.20)
(1317.63)
(1501.78)
(460.38)
Table DD-4 — (Continued)
Model No.
L
M
N
P
R
S
T
U
V
W
TWE155B
19-1/2
77-1/4
1-1/4
48
35
35
2-7/8
73-7/8
3-3/4
3-3/8
(495.30)
(1962.15)
(31.75)
(1219.20)
(889.00)
(889.00)
(73.03)
(1876.43)
(95.25)
(85.73)
TWE200B
20-7/8
89-1/4
1-3/4
50-7/8
39-1/8
39-1/8
4-7/8
82-7/8
4-5/8
3-1/8
(530.23)
(2266.95)
(44.45)
(1292.23)
(993.78)
(993.78)
(123.83)
(2105.03)
(117.48)
(79.38)
Table DD-4 — (Continued)
Model No.
Y
Z
AA
AB
AC
AD
AE
AF
TWE155B
18
73-7/8
3-3/4
2-7/8
18
3-5/8
35
35
(457.20)
(1876.43)
(95.25)
(73.03)
(457.20)
(92.08)
(889.00)
(889.00)
TWE200B
20-1/8
82-7/8
4-5/8
4-7/8
20-1/8
3
39-1/8
39-1/8
(511.18)
(2105.03)
(117.48)
(123.83)
(511.18)
(76.20)
(993.78)
(993.78)
