Features
and Benefits
Odyssey — A Complete Split
System
Odyssey delivers the flexibility to select
a complete system that meets your
particular job requirements. Air
handlers are designed, tested, and
rated with outdoor units to let you
select the proper match between
capacity and load. Heat pumps can also
be matched with Trane built-up air
handlers. Also, these matched systems
can be quickly engineered for specific
applications using Trane’s computerized
selection and load programs.
Odyssey air handler versatility is further
increased by a complete line of
accessories designed to match and install
smoothly:
•
Discharge Plenum and Grille
•
Return Grille
•
Subbase
•
Electric Heaters
•
High Static Evaporator Motor
•
Isolators both Rubber-in-Shear and
Spring Type
•
A Full Line of Thermostats
•
Outdoor Thermostat
Odyssey Lowers
Installation Costs
Your installation costs are reduced with
Odyssey. Both outdoor units and air
handlers are factory packaged and
assembled so jobsite installation is quick
and easy. You get a complete unit with all
the components, controls and the internal
wiring factory ready for a smooth jobsite
start-up.
Unlike some competitive models the
following components are factory-
installed in Trane air handlers:
l
Single Point Power Entry
l
Blower wheel and housing
l
Evaporator motor with
sheaves and pulleys
l
Low Voltage Terminal Board
l
Transformer
l
Contactor
l
Fan relay
l
DX Coil with complete
refrigeration circuitry
l
Expansion Valve and
Check Valves
There’s no need to install components
and put together the air handler on the
job. This provides you with less labor cost
and fewer chances for installation errors
which cause callbacks. All this means
saving you money both in replacement
and new construction applications.
(Most Models)
