Dimensional
Data
Figure DD-14 — TWE200E Air Handler
All dimensions are in inches and millimeters.
Table DD-5 — Air Handler Dimensions — in.(mm)
Model No.
A
B
C
D
E
F
G
H
J
K
L
M
N
P
R
TWE200E
71 7/8"
92 5/8"
30 1/2"
18 7/8"
4 1/2"
28 1/2"
28"
51 7/8"
59 1/8"
18 1/8"
20 7/8"
89 1/4"
1 3/4"
50 7/8"
39 1/8"
(1826)
(2353)
(775)
(479)
(114)
(724)
(711)
(1318)
(1502)
(460)
(530)
(2267)
(45)
(1292)
(994)
Table DD-5 — (Continued)
Model No.
S
T
U
V
W
Y
Z
AA
AB
AC
AD
AE
AF
TWE200E
39 1/8"
4 7/8"
82 7/8"
4 5/8"
3 1/8"
20 1/8"
82 7/8"
4 5/8"
4 7/8"
20 1/8"
3 1/8"
39 1/8"
39 1/8"
(994)
(124)
(2105)
(118)
(79)
(511)
(2105)
(117)
(124)
(511)
(79)
(994)
(994)
