Table PD-41 — Auxiliary Electric Heat Capacity — Air Handler

No.

Stage 1

Stage 2

Total

Unit

Total

of

kW

Btu

kW

Btu

kW

Btu

Model No.

kW

Stages

Input

Output

Input

Output

Input

Output

5.00

1

5.00

17,065

5.00

17,065

TWE050/075/100AD

9.96

1

9.96

33,993

9.96

33,993

TWE100BD

14.96

1

14.96

51,058

14.96

51,058

24.92

2

14.96

51,058

9.96

33,993

24.92

85,051

TWE075, 100AD
TWE100BD

34.88

2

19.92

67,987

14.96

51,058

34.88

119,045

10.00

1

10.00

34,130

10.00

34,130

TWE155,200B, 200E

19.92

1

19.92

67,987

19.92

67,987

29.92

2

19.92

67,987

10.00

34,130

29.92

102,117

49.84

2

29.92

102,117

19.92

67,987

49.84

170,104

*Heaters are rated at 400v. For other than rated voltage,

Capacity =

Voltage

2

x Rated Capacity and kW =

Voltage

2

Rated kW.

(

Rated Voltage

)

(

Rated Voltage

)
