Performance
Data
Condensing Unit
Table PD-19 — Cooling Performance (MBh) TTA100A Condensing Unit Only (I-P)
OD Temp
Suction Reference Temperature °F
°F
30
35
40
45
50
55
Head press PSIG
166
172
178
185
192
200
65
Cap. Btuh/1000
101.6
111.9
122.6
133.8
145.5
157.6
OD Unit KW
6.30
6.46
6.63
6.81
7.01
7.22
Head press PSIG
191
197
203
210
218
226
75
Cap. Btuh/1000
97.1
106.8
116.9
127.6
138.7
150.3
OD Unit KW
6.95
7.12
7.30
7.50
7.71
7.94
Head press PSIG
218
224
231
238
246
254
85
Cap. Btuh/1000
92.3
101.4
111.1
121.3
131.9
143.0
OD Unit KW
7.73
7.91
8.11
8.32
8.55
8.79
Head press PSIG
248
254
261
269
277
286
95
Cap. Btuh/1000
87.1
95.8
105.1
114.8
125.0
135.7
OD Unit KW
8.64
8.83
9.04
9.27
9.50
9.75
Head press PSIG
280
287
294
302
311
320
105
Cap. Btuh/1000
81.6
90.1
99.0
108.4
118.1
128.3
OD Unit KW
9.66
9.87
10.10
10.34
10.59
10.84
Head press PSIG
315
322
330
339
348
357
115
Cap. Btuh/1000
76.0
84.1
92.8
101.8
111.1
120.8
OD Unit KW
10.80
11.04
11.28
11.54
11.79
12.05
Performance Data Calculated at 15 deg. subcooling and 15 deg. superheat.
Table PD-19 — Cooling Performance (kW)
TTA100A Condensing Unit Only
(SI)
OD Temp
Suction Reference Temperature °C
°C
-1.1
1.7
4.4
7.2
10.0
12.8
Head pressure (kPA)
1146
1187
1230
1276
1326
1378
18.3
Capacity (kW)
29.8
32.8
35.9
39.2
42.6
46.1
OD Unit Power (kW)
6.30
6.46
6.63
6.81
7.01
7.22
Head pressure (kPA)
1316
1358
1402
1450
1501
1556
23.9
Capacity (kW)
28.4
31.3
34.2
37.4
40.6
44.0
OD Unit Power (kW)
6.95
7.12
7.30
7.50
7.71
7.94
Head pressure (kPA)
1502
1546
1593
1643
1696
1753
29.4
Capacity (kW)
27.0
29.7
32.5
35.5
38.6
41.9
OD Unit Power (kW)
7.73
7.91
8.11
8.32
8.55
8.79
Head pressure (kPA)
1707
1753
1802
1854
1910
1969
35.0
Capacity (kW)
25.5
28.1
30.8
33.6
36.6
39.7
OD Unit Power (kW)
8.64
8.83
9.04
9.27
9.50
9.75
Head pressure (kPA)
1929
1977
2030
2085
2144
2205
40.6
Capacity (kW)
23.9
26.4
29.0
31.7
34.6
37.6
OD Unit Power (kW)
9.66
9.87
10.10
10.34
10.59
10.84
Head pressure (kPA)
2169
2221
2277
2335
2397
2461
46.1
Capacity (kW)
22.2
24.6
27.2
29.8
32.5
35.4
OD Unit Power (kW)
10.80
11.04
11.28
11.54
11.79
12.05
Performance Data Calculated at 8.3 deg. subcooling and 8.3 deg. superheat.
