Dimensional
Data
Figure DD-17 — Discharge Plenum and Grille
All dimensions are in inches and millimeters.
Figure DD-18 — Subbase
Table DD-8 — Subbase Dimensions
— in. (mm)
Model
Model No.
A
B
TWE050
BAYBASE001
38
22
(965.2)
(558.8)
TWE075
BAYBASE002
47
1
/
2
25
(1206.5)
(635)
TWE100
BAYBASE003
63
1
/
2
25
(1612.9)
(635)
TWE155
BAYBASE004
79
1
/
2
27
5
/
8
(2019.3)
(701.7)
TWE200
BAYBASE005
92
1
/
2
30
3
/
8
(2349.5)
(771.5)
Table DD-6 — Discharge Plenum And
Grille Dimensions — in. (mm)
Model
Model No.
A
B
C
TWE050
BAYPLNM015
37
7
/
8
21
7
/
8
28
(962)
(555.6) (711.2)
TWE075
BAYPLNM016
47
1
/
2
25
28
(1206.5) (635)
(711.2)
TWE100
BAYPLNM017
63
1
/
2
25
28
(1612.9) (635)
(711.2)
Table DD-7 — Discharge Plenum And
Grille Dimensions — in. (mm)
For Use with Electric Heat
Model
Model No.
A
B
C
TWE050
BAYPLNM025
37
7
/
8
21
7
/
8
29
(962) (555.6) (736.6)
TWE075
BAYPLNM026
47
1
/
2
25
29
(1206.5) (635) (736.6)
TWE100
BAYPLNM027
63
1
/
2
25
29
(1612.9) (635) (736.6)
TWE155
BAYPLNM028
79
1
/
2
27
5
/
8
35
(2019.3) (701.7)
(889)
TWE200
BAYPLNM029
92
1
/
2
30
3
/
8
35
(2349.5) (771.5) (889)
