Performance
Data
System
Table PD-3 — Gross Cooling Capacities (kW)
TTA085A Condensing Unit with TWE075A Air Handler
(SI)
Ambient Temperature (°C)
29.4
35.0
40.6
46.1
Enter.
Dry
Entering Wet Bulb (°C)
m
3
/h
Bulb
16.1
19.4
22.8
16.1
19.4
22.8
16.1
19.4
22.8
16.1
19.4
22.8
Airflow
(°C)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
24
24.2
18.5
26.8
15.6
29.8
10.9
23.3
18.0
25.9
15.2
28.7
10.5
22.4
17.6
24.9
14.8
27.6
10.1
21.5
17.1
23.9
14.4
26.5
9.7
3823
27
24.2
21.3
26.9
17.9
29.8
14.1
23.4
20.9
26.0
17.4
28.7
13.7
22.5
20.5
25.0
17.0
27.7
13.3
21.6
20.0
24.0
16.6
26.5
12.8
29
24.6
24.4
27.0
20.8
29.9
17.1
23.7
23.7
26.0
20.3
28.8
16.7
23.0
23.0
25.0
19.9
27.7
16.3
22.2
22.2
24.0
19.4
26.6
15.9
32
25.7
25.7
27.0
23.7
29.9
20.1
25.0
25.0
26.1
23.2
28.9
19.7
24.2
24.2
25.2
22.8
27.8
19.3
23.4
23.4
24.2
22.3
26.7
18.8
24
24.7
19.3
27.4
15.4
30.3
11.1
23.8
18.8
26.4
15.0
29.3
10.7
22.9
18.4
25.4
14.5
28.1
10.3
21.9
17.9
24.3
14.1
26.9
9.9
4248
27
24.8
22.5
27.5
18.7
30.4
14.5
24.0
22.0
26.5
18.3
29.3
14.1
23.1
21.6
25.4
17.7
28.2
13.7
22.1
21.1
24.4
17.3
27.0
13.3
29
25.3
25.3
27.5
21.8
30.5
17.8
24.6
24.6
26.6
21.4
29.4
17.4
23.8
23.8
25.6
20.9
28.3
17.0
23.0
23.0
24.5
20.4
27.1
16.6
32
26.6
26.6
27.7
25.0
30.5
21.1
25.9
25.9
26.7
24.6
29.4
20.6
25.1
25.1
25.8
24.1
28.3
20.2
24.3
24.3
24.8
23.7
27.2
19.7
24
25.2
20.1
27.9
15.9
30.8
11.3
24.3
19.6
26.9
15.5
29.7
10.9
23.3
19.2
25.8
15.0
28.5
10.5
22.3
18.7
24.7
14.6
27.3
10.1
4672
27
25.3
23.5
27.9
19.4
30.9
15.0
24.5
23.1
26.9
18.9
29.7
14.6
23.5
22.6
25.9
18.5
28.6
14.1
22.6
22.2
24.8
18.0
27.4
13.7
29
26.1
26.1
28.0
22.8
31.0
18.5
25.3
25.3
27.0
22.3
29.8
18.1
24.5
24.5
26.0
21.9
28.7
17.7
23.7
23.7
24.9
21.4
27.5
17.3
32
27.5
27.5
28.2
26.3
31.0
22.0
26.7
26.7
27.3
25.8
29.9
21.5
25.9
25.9
26.3
25.4
28.8
21.1
25.0
25.0
25.3
24.9
27.6
20.6
24
25.6
20.8
28.3
16.4
31.2
11.5
24.6
20.4
27.2
15.9
30.0
11.1
23.6
19.9
26.2
15.5
28.8
10.7
22.6
19.4
25.0
15.0
27.6
10.2
5097
27
25.8
24.6
28.3
20.1
31.3
15.4
24.9
24.1
27.3
19.6
30.1
15.0
24.0
23.7
26.2
19.1
28.9
14.5
22.9
22.9
25.1
18.6
27.7
14.1
29
26.8
26.8
28.5
23.7
31.4
19.2
26.0
26.0
27.4
23.3
30.2
18.8
25.1
25.1
26.4
22.8
29.1
18.4
24.3
24.3
25.3
22.3
27.8
17.8
32
28.2
28.2
28.7
27.5
31.4
22.8
27.4
27.4
27.8
27.0
30.3
22.4
26.5
26.5
26.8
26.6
29.1
21.9
25.6
25.6
25.7
25.7
27.9
21.5
Equal TGC and SHC values constitute dry coil conditions. Total Gross Cooling (TGC) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total
capacity.
All capacities shown are gross and have not considered indoor fan heat.
To obtain net cooling capacities subtract indoor fan heat.
TGC = Total Gross Cooling Capacity
SHC = Sensible Heat Capacity
Table PD-3 — Gross Cooling Capacities (MBh)
TTA085A Condensing Unit with TWE075A Air Handler
(I-P)
Ambient Temperature (°F)
85
95
105
115
Enter.
Dry
Entering Wet Bulb (°F)
CFM
Bulb
61
67
73
61
67
73
61
67
73
61
67
73
Airflow
(°F)
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
TGC
SHC
75
82.5
63.0
91.6
53.2 101.7 37.2
79.6
61.5
88.4
51.9
98.1
35.9
76.5
60.0
85.0
50.5
94.3
34.6
73.3
58.3
81.5
49.1
90.4
33.2
2250
80
82.8
72.9
91.9
61.0 101.7 48.1
80.0
71.4
88.7
59.6
98.2
46.7
77.0
69.9
85.4
58.1
94.5
45.3
73.8
68.3
81.9
56.6
90.6
43.8
85
84.0
83.3
92.1
70.9 102.0 58.4
81.0
81.0
88.9
69.4
98.4
57.0
78.5
78.5
85.5
67.9
94.8
55.6
75.9
75.9
82.1
66.3
90.9
54.1
90
87.7
87.7
92.4
80.8 102.2 68.7
85.3
85.3
89.3
79.4
98.7
67.3
82.7
82.7
86.0
77.9
95.0
65.9
80.1
80.1
82.6
76.3
91.0
64.1
75
84.4
65.9
93.6
52.5 103.7 37.9
81.4
64.4
90.3
51.1
99.9
36.6
78.2
62.8
86.8
49.6
96.0
35.3
74.8
61.1
83.1
48.1
91.9
33.9
2500
80
84.8
76.7
93.9
63.8 103.7 49.6
81.9
75.2
90.6
62.3 100.0 48.2
78.8
73.7
86.9
60.6
96.2
46.8
75.6
72.1
83.3
59.0
92.2
45.3
85
86.4
86.4
94.1
74.4 104.0 60.9
83.9
83.9
90.8
72.9 100.4 59.5
81.3
81.3
87.3
71.4
96.5
58.1
78.6
78.6
83.7
69.8
92.6
56.6
90
90.9
90.9
94.5
85.3 104.3 72.1
88.4
88.4
91.3
83.9 100.4 70.4
85.7
85.7
88.0
82.4
96.7
68.9
82.9
82.9
84.5
80.8
92.7
67.3
75
85.9
68.6
95.2
54.2 105.2 38.7
82.8
67.0
91.8
52.8 101.4 37.3
79.5
65.4
88.2
51.3
97.3
36.0
76.1
63.7
84.4
49.8
93.1
34.5
2750
80
86.5
80.4
95.3
66.1 105.4 51.1
83.5
78.9
91.9
64.6 101.6 49.7
80.4
77.3
88.4
63.0
97.6
48.2
77.1
75.7
84.7
61.4
93.5
46.8
85
89.0
89.0
95.7
77.8 105.7 63.3
86.4
86.4
92.3
76.3 101.9 61.9
83.7
83.7
88.8
74.7
98.0
60.4
80.9
80.9
85.1
73.1
93.9
59.0
90
93.8
93.8
96.4
89.7 105.8 75.0
91.1
91.1
93.2
88.2 102.1 73.5
88.3
88.3
89.8
86.7
98.2
72.0
85.4
85.4
86.3
85.1
94.2
70.4
75
87.3
71.2
96.6
55.9 106.6 39.4
84.1
69.6
93.1
54.4 102.6 38.0
80.7
68.0
89.4
52.9
98.5
36.5
77.2
66.2
85.5
51.3
94.2
35.0
3000
80
88.1
83.9
96.8
68.5 106.8 52.5
85.1
82.4
93.3
67.0 102.9 51.1
81.9
80.8
89.6
65.3
98.9
49.6
78.3
78.3
85.8
63.7
94.7
48.1
85
91.4
91.4
97.2
81.0 107.2 65.6
88.7
88.7
93.7
79.5 103.3 64.2
85.9
85.9
90.1
77.9
99.3
62.7
82.9
82.9
86.3
76.3
94.9
60.8
90
96.3
96.3
98.2
93.9 107.3 78.0
93.5
93.5
94.9
92.4 103.5 76.5
90.6
90.6
91.4
90.8
99.5
74.9
87.6
87.6
87.6
87.6
95.4
73.3
Equal TGC and SHC values constitute dry coil conditions. Total Gross Cooling (TGC) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total
capacity.
All capacities shown are gross and have not considered indoor fan heat.
To obtain net cooling capacities subtract indoor fan heat.
TGC = Total Gross Cooling Capacity
SHC = Sensible Heat Capacity
