Table PD-27 — Cooling Capacities (MBh) TTA200B Condensing Unit Only

(I-P)

OD Temp

Suction Reference Temperature °F

°F

30

35

40

45

50

55

Head press PSIG

168

174

180

186

193

200

65

Cap. Btuh/1000

198.0

217.3

237.4

258.3

280.0

302.5

OD Unit KW

12.47

12.77

13.08

13.42

13.79

14.18

Head press PSIG

194

200

206

213

220

227

75

Cap. Btuh/1000

188.9

207.0

226.1

245.9

266.6

288.2

OD Unit KW

13.83

14.16

14.50

14.88

15.28

15.71

Head press PSIG

222

228

235

242

249

257

85

Cap. Btuh/1000

179.1

196.3

214.4

233.4

253.2

273.7

OD Unit KW

15.45

15.80

16.19

16.59

17.03

17.48

Head press PSIG

253

259

266

274

282

290

95

Cap. Btuh/1000

168.7

185.1

202.5

220.6

239.6

259.2

OD Unit KW

17.31

17.70

18.12

18.56

19.02

19.50

Head press PSIG

286

293

301

309

317

326

105

Cap. Btuh/1000

157.8

173.7

190.3

207.7

225.9

244.6

OD Unit KW

19.42

19.85

20.31

20.78

21.26

21.75

Head press PSIG

321

329

337

346

355

364

115

Cap. Btuh/1000

146.5

161.9

177.9

194.7

212.0

229.8

OD Unit KW

21.75

22.23

22.73

23.23

23.74

24.23

Performance Data Calculated at 15 deg. subcooling and 15 deg. superheat.

Performance
Data

Condensing Unit

Table PD-27 — Cooling Capacities (MBh) TTA200B Condensing Unit Only

(SI)

OD Temp

Suction Reference Temperature °C

°C

-1.1

1.7

4.4

7.2

10.0

12.8

Head pressure (kPA)

1159

1198

1239

1282

1327

1376

18.3

Capacity (kW)

58.0

63.6

69.5

75.6

82.0

88.6

OD Unit Power (kW)

12.47

12.77

13.08

13.42

13.79

14.18

Head pressure (kPA)

1336

1377

1420

1466

1514

1565

23.9

Capacity (kW)

55.3

60.6

66.2

72.0

78.1

84.4

OD Unit Power (kW)

13.83

14.16

14.50

14.88

15.28

15.71

Head pressure (kPA)

1530

1573

1619

1668

1719

1773

29.4

Capacity (kW)

52.4

57.5

62.8

68.3

74.1

80.1

OD Unit Power (kW)

15.45

15.80

16.19

16.59

17.03

17.48

Head pressure (kPA)

1741

1788

1836

1888

1943

2000

35.0

Capacity (kW)

49.4

54.2

59.3

64.6

70.1

75.9

OD Unit Power (kW)

17.31

17.70

18.12

18.56

19.02

19.50

Head pressure (kPA)

1970

2020

2072

2128

2185

2246

40.6

Capacity (kW)

46.2

50.8

55.7

60.8

66.1

71.6

OD Unit Power (kW)

19.42

19.85

20.31

20.78

21.26

21.75

Head pressure (kPA)

2216

2270

2327

2386

2448

2511

46.1

Capacity (kW)

42.9

47.4

52.1

57.0

62.1

67.3

OD Unit Power (kW)

21.75

22.23

22.73

23.23

23.74

24.23

Performance Data Calculated at 8.3 deg. subcooling and 8.3 deg. superheat.
