Table PD-26 — Cooling Performance (MBh) - Single Compressor - (I-P)
TTA155C Condensing Unit Only
OD Temp
Suction Reference Temperature °F
°F
30
35
40
45
50
55
Head press. PSIG
139.0
141.9
145.1
148.5
152.1
155.9
65
Cap. Btuh/1000
71.8
79.5
87.9
96.8
106.2
116.1
OD Unit KW
4.9
4.9
5.0
5.1
5.1
5.2
Head press. PSIG
163.0
166.2
169.6
173.1
176.9
180.8
75
Cap. Btuh/1000
70.8
78.4
86.5
95.1
104.0
113.3
OD Unit KW
5.3
5.3
5.4
5.5
5.6
5.7
Head press. PSIG
189.4
192.8
196.4
200.1
204.0
208.0
85
Cap. Btuh/1000
68.9
76.4
84.2
92.4
100.9
109.6
OD Unit KW
5.8
5.9
5.9
6.0
6.1
6.2
Head press. PSIG
218.1
221.8
225.6
229.5
233.6
237.8
95
Cap. Btuh/1000
66.3
73.5
81.0
88.8
96.9
105.3
OD Unit KW
6.4
6.5
6.5
6.6
6.7
6.8
Head press. PSIG
249.6
253.5
257.5
261.6
265.9
270.3
105
Cap. Btuh/1000
63.0
69.9
77.1
84.5
92.3
100.3
OD Unit KW
7.1
7.2
7.2
7.3
7.4
7.5
Head press. PSIG
283.6
287.8
292.0
296.3
300.8
305.5
115
Cap. Btuh/1000
59.1
65.6
72.5
79.6
87.0
94.7
OD Unit KW
7.9
7.9
8.0
8.1
8.2
8.2
Performance Data Calculated at 15 deg. subcooling and 15 deg. superheat.
Table PD-26 — Cooling Performance (kW) - Single Compressor - (SI)
TTA155C Condensing Unit Only
OD Temp
Suction Reference Temperature °C
°C
-1.1
1.7
4.4
7.2
10.0
12.8
Head pressure (kPA)
959
979
1000
1024
1049
1075
18.3
Capacity (kW)
21.0
23.3
25.7
28.3
31.1
34.0
OD Unit Power (kW)
4.89
4.93
4.99
5.06
5.13
5.21
Head pressure (kPA)
1124
1146
1169
1194
1220
1246
23.9
Capacity (kW)
20.7
23.0
25.3
27.8
30.5
33.2
OD Unit Power (kW)
5.29
5.35
5.42
5.49
5.57
5.66
Head pressure (kPA)
1306
1329
1354
1380
1406
1434
29.4
Capacity (kW)
20.2
22.4
24.7
27.0
29.5
32.1
OD Unit Power (kW)
5.79
5.86
5.93
6.01
6.10
6.18
Head pressure (kPA)
1504
1529
1555
1583
1611
1640
35.0
Capacity (kW)
19.4
21.5
23.7
26.0
28.4
30.8
OD Unit Power (kW)
6.38
6.46
6.54
6.62
6.70
6.79
Head pressure (kPA)
1721
1748
1775
1804
1833
1864
40.6
Capacity (kW)
18.4
20.5
22.6
24.7
27.0
29.4
OD Unit Power (kW)
7.08
7.15
7.23
7.31
7.39
7.48
Head pressure (kPA)
1956
1984
2013
2043
2074
2107
46.1
Capacity (kW)
17.3
19.2
21.2
23.3
25.5
27.7
OD Unit Power (kW)
7.86
7.93
8.00
8.08
8.16
8.25
Performance Data Calculated at 8.3 deg. subcooling and 8.3 deg. superheat.
