47 SS-PRC003-EN
Table PD-39— Discharge Plenum And Grille Assembly Throw Distance — Air Handle — ft (m)
Unit Louver Angle Deflection Position
Model No. CFM m 3 /h Straight 20 40 55
1400 2380 38 (11.6) 24 (7.3) 22 (6.7) 18 (5.5)
1600 2718 42 (12.8) 31 (9.4) 26 (7.9) 20 (6.1)
TWE050 1800 3060 46 (14.0) 37 (11.3) 29 (8.8) 22 (6.7)
2000 3398 48 (14.6) 43 (13.1) 33 (10.1) 24 (7.3)
2200 3737 51 (15.5) 50 (15.2) 36 (11.0) 25 (7.6)
2100 3568 49 (14.9) 38 (11.6) 31 (9.4) 27 (8.2)
TWE075 2400 4079 52 (15.9) 43 (13.1) 35 (10.7) 29 (8.8)
2700 4586 55 (16.8) 48 (14.6) 38 (11.6) 31 (9.4)
3000 5098 58 (17.7) 53 (16.2) 42 (12.8) 32 (9.8)
3200 5436 56 (17.1) 46 (14.0) 38 (11.6) 30 (9.1)
3600 6116 62 (18.9) 51 (15.5) 42 (12.8) 33 (10.1)
TWE100 4000 6797 66 (20.1) 57 (17.4) 47 (14.3) 35 (10.7)
4400 7477 71 (21.6) 62 (18.9) 52 (15.9) 38 (11.6)
4800 8154 76 (23.2) 67 (20.4) 56 (17.1) 42 (12.8)
4300 7304 42 (12.8) 32 (9.8) 29 (8.8) 21 (6.4)
4900 8327 47 (14.3) 38 (11.6) 32 (9.8) 25 (7.6)
TWE155 5400 9176 52 (15.9) 44 (13.4) 37 (11.3) 29 (8.8)
6000 10195 57 (17.4) 49 (14.9) 41 (12.5) 32 (9.8)
5600 9515 50 (15.2) 40 (12.2) 33 (10.1) 27 (8.2)
6400 10872 56 (17.1) 46 (14.0) 38 (11.6) 30 (9.1)
TWE200 7200 12233 62 (18.9) 51 (15.5) 42 (12.8) 33 (10.1)
8000 13594 66 (20.1) 57 (17.4) 47 (14.3) 35 (10.7)
Throw distance values are based on a terminal velocity of 75 FPM (0.38 m/s).
Throw distance values at other terminal velocities may be established by multiplying throw distances in table
above by throw factor:
Terminal Velocity
Throw Factor
50 fpm (.25 m/s) x 1.50
100 fpm (.51 m/s) x .75
150 fpm (.76 m/s) x .50
Performance
Data
Table PD-40— Static Pressure Drop Through Accessories (Inches Of Water Column) 1 — Air Handler
Discharge Electric Heaters (kW)
Unit Return Grille Plenum and Grille 2 5-10 15-20 25-30 35-50
Model No. CFM m 3 /h In. wc 1 Pascal In. wc 1 Pascal In. wc (Pascal)
1400 2380 .09 (22.4) .16 (39.8) .06 (15.0) .06 (15.0) .12 (29.9) —
TWE050A 1600 2718 .12 (29.9) .21 (52.3) 08 (19.9) .08 (19.9) .14 (34.9) —
2000 3398 .18 (44.8) .33 (82.2) .13 (32.4) .13 (32.4) .19 (47.3) —
2100 3568 .05 (12.5) .19 (47.3) .02 (5.0) .03 (7.5) .05 (12.5) .08 (19.9)
TWE075A 2400 4079 .08 (19.9) .27 (67.2) .03 (7.5) .06 (15.0) .08 (19.9) .12 (29.9)
3000 5098 .13 (32.4) .40 (99.6) .06 (15.0) .12 (29.9) .17 (42.4) .23 (57.3)
TWE100A 2800 4756 .04 (10.0) .34 (84.7) .03 (7.5) .04 (10.0) .14 (34.9) .20 (49.8)
TWE100B 3200 5436 .07 (17.4) .43 (107.1) .06 (15.0) .13 (32.4) .19 (47.3) .26 (64.8)
4300 7304 .07 (17.4) .18 (44.8) .02 (5.0) .02 (5.0) .04 (10.0) .05 (12.5)
TWE155B 4800 8154 .09 (22.4) .23 (57.3) .03 (7.5) .03 (7.5) .06 (15.0) .08 (19.9)
6000 10195 .15 (37.4) .34 (84.7) .06 (15.0) .06 (15.0) .12 (29.9) .17 (42.4)
5600 9515 .07 (17.4) .32 (79.7) .04 (10.0) .04 (10.0) .10 (25.0) .15 (37.4)
TWE200B,E 6400 10872 .11 (27.4) .43 (107.1) .06 (15.0) .06 (15.0) .13 (32.4) .19 (47.3)
8000 13594 .17 (42.3) .66 (164.3) .10 (25.0) .10 (25.0) .20 (49.8) .30 (74.7)
1. Return air filter ESP included in Fan Performance Table data.
2. At louver opening angle of 42°F (5.5°C). For ESP at other angle openings, see accessory Installer’s Guide.
