Performance
Data
Condensing Unit
Table PD-18 — Cooling Performance (MBh)
TTA085A Condensing Unit Only (I-P)
OD Temp
Suction Reference Temperature °F
°F
30
35
40
45
50
55
Head press PSIG
154
159
164
169
175
180
65
Cap. Btuh/1000
82.0
90.5
99.4
108.7
118.4
128.5
OD Unit KW
4.93
5.03
5.13
5.24
5.36
5.49
Head press PSIG
178
183
188
194
199
205
75
Cap. Btuh/1000
78.5
86.5
94.9
103.8
113.0
122.7
OD Unit KW
5.41
5.51
5.63
5.75
5.88
6.02
Head press PSIG
205
210
215
221
227
233
85
Cap. Btuh/1000
74.7
82.3
90.3
98.7
107.6
116.9
OD Unit KW
6.00
6.11
6.23
6.36
6.49
6.64
Head press PSIG
234
239
245
251
257
264
95
Cap. Btuh/1000
70.7
77.9
85.5
93.6
102.1
111.0
OD Unit KW
6.69
6.80
6.93
7.07
7.22
7.37
Head press PSIG
265
271
277
283
290
297
105
Cap. Btuh/1000
66.4
73.3
80.7
88.4
96.6
105.0
OD Unit KW
7.48
7.61
7.74
7.89
8.04
8.20
Head press PSIG
300
306
312
319
326
333
115
Cap. Btuh/1000
61.9
68.6
75.7
83.2
91.0
99.1
OD Unit KW
8.37
8.51
8.66
8.81
8.97
9.13
Performance Data Calculated at 15 deg. subcooling and 15 deg. superheat.
Table PD-18 — Cooling Performance (kW)
TTA085A Condensing Unit Only
(SI)
OD Temp Suction Reference Temperature °C
°C
-1.1
1.7
4.4
7.2
10.0
12.8
Head pressure (kPA)
1063
1095
1129
1165
1203
1244
18.3
Capacity (kW)
24.0
26.5
29.1
31.8
34.7
37.6
OD Unit Power (kW)
4.93
5.03
5.13
5.24
5.36
5.49
Head pressure (kPA)
1229
1262
1297
1334
1374
1416
23.9
Capacity (kW)
23.0
25.3
27.8
30.4
33.1
35.9
OD Unit Power (kW)
5.41
5.51
5.63
5.75
5.88
6.02
Head pressure (kPA)
1412
1446
1482
1521
1563
1607
29.4
Capacity (kW)
21.9
24.1
26.4
28.9
31.5
34.2
OD Unit Power (kW)
6.00
6.11
6.23
6.36
6.49
6.64
Head pressure (kPA)
1612
1648
1686
1727
1771
1817
35.0
Capacity (kW)
20.7
22.8
25.0
27.4
29.9
32.5
OD Unit Power (kW)
6.69
6.80
6.93
7.07
7.22
7.37
Head pressure (kPA)
1830
1869
1910
1953
1999
2047
40.6
Capacity (kW)
19.4
21.5
23.6
25.9
28.3
30.8
OD Unit Power (kW)
7.48
7.61
7.74
7.89
8.04
8.20
Head pressure (kPA)
2067
2109
2153
2199
2246
2297
46.1
Capacity (kW)
18.1
20.1
22.2
24.4
26.6
29.0
OD Unit Power (kW)
8.37
8.51
8.66
8.81
8.97
9.13
Performance Data Calculated at 8.3 deg. subcooling and 8.3 deg. superheat.
