General
Data
Table GD-3 — General Data
TWE050A
TWE075A
TWE100A
TWE100B
System Data
1
No. Refrigerant Circuits
1
1
1
2
Suction Line in. (mm) OD
1.120(28.4)
1.380(35.0)
1.380(35.0)
1.380(35.0)
Liquid Line in. (mm) OD
0.38(9.7)
0.50(12.7)
0.50(12.7)
0.50(12.7)
Indoor Coil — Type
Plate Fin
Plate Fin
Plate Fin
Plate Fin
Tube Size in. (mm) OD
0.375(9.5)
0.375(9.5)
0.375(9.5)
0.375(9.5)
Face Area sq. ft (m
2
)
5.00(.47)
8.07(.75)
11.18(1.0)
11.18(1.0)
Rows
3
3
4
4
Fins Per Inch
12
12
12
12
Refrigerant Control
Expansion Valve
Expansion Valve
Expansion Valve
Expansion Valve
Drain Connection No.
4
4
4
4
Drain Connection Size in. (mm)
0.75(19.0)
0.75(19.0)
0.75(19.0)
0.75(19.0)
Drain Connection Type
PVC
PVC
PVC
PVC
Indoor Fan Type
FC Centrifugal
FC Centrifugal
FC Centrifugal
FC Centrifugal
No. Used
1
1
1
1
Diameter in. (mm)
12.0(304.8)
15.0(381)
15.0(381)
15.0(381)
Width in. (mm)
12.0(304.8)
15.0(381)
15.0(381)
15.0(381)
Drive Type
Belt
Belt
Belt
Belt
No. Speeds
1
1
1
1
CFM (m
3
/h)
1670(2837)
2500(4247)
3325(5649)
3325(5649)
No. Motors
1
1
1
1
Motor HP (kW)
- Standard/Oversized
0.75/1.0(.55/.74)
1.0/1.5(.74/1.11)
1.5/2.0(1.11/1.49)
1.5/2.0(1.11/1.49)
Motor RPM (Standard)
1425
1425
1425
1425
Motor Frame Size (Standard)
56
56
56
56
Filters — Type
Throwaway
Throwaway
Throwaway
Throwaway
Furnished
Yes
Yes
Yes
Yes
No.
1/1
3
4
4
Recommended Size, in. (mm) 16x20x1/20x20x1
16x25x1
16x25x1
16x25x1
(406.4x508x25.4/
(406.4x635x25.4)
(406.4x635x25.4)
(406.4x635x25.4)
508x508x25.4)
Notes:
1. ARI certified with various condensing units per ARI Standard 210/240 or 340/360 or 365-00. Refer to Performance
Data section in this catalog.
Table GD-4 — General Data
TWE155B
TWE200B,E
System Data
No. Refrigerant Circuits
2
2
Suction Line in. (mm) OD
1.38(35.0)
1.38(35.0)
Liquid Line in. (mm) OD
0.500(12.7)
0.500(12.7)
Indoor Coil — Type
Plate Fin
Plate Fin
Tube Size in. (mm) OD
0.375(9.5)
0.375(9.5)
Face Area sq. ft (m
2
)
16.33(1.52)
21.63(2.01)
Rows
3
3
Fins Per Inch
12
12
Refrigerant Control
Expansion Valve
Expansion Valve
Drain Connection No.
4
4
Drain Connection Size in. (mm)
1.000(25.4)
1.000(25.4)
Drain Connection Type
PVC
PVC
Indoor Fan Type
FC Centrifugal
FC Centrifugal
No. Used
2
2
Diameter in. (mm)
15.0(381)
15.0(381)
Width in. (mm)
15.0(381)
15.0(381)
Drive Type
Belt
Belt
No. Speeds
1
1
CFM (m
3
/h)
5000(8494)
6650(11297)
No. Motors
1
1
Motor HP — Standard/Oversized
2.0/3.0(1.49/2.24)
3.0/5.0(2.24/3.72)
Motor RPM (Standard)
1425
1425
Motor Frame Size (Standard)
145T
184T
Filters — Type
Throwaway
Throwaway
Furnished
Yes
Yes
No.
8
4/4
Recommended Size, in. (mm)
15x20x2
16x20x2/16x25x2
(381x508x50.8)
(406.4x508x50.8/
406.4x635x50.8)
Notes:
1. ARI certified with various condensing units per ARI Standard 210/240 or 340/360 or 365-00. Refer to Performance
Data section in this catalog.
Air Handler
