49 SS-PRC003-EN
Electrical
Data
Table ED-4 — Unit Wiring — Air Handler
Minimum Maximum Fuse
Unit Unit Operating Circuit Size or Maximum
Model No. Voltage Range Ampacity Circuit Breaker
TWE050 380/415 4 15
TWE075 380/415 5 15
TWE100 380/415 5 15
TWE155 380/415 6 15
TWE200 380/415 10 15
Table ED-1 — Unit Wiring — Condensing Units
Minimum Maximum Fuse Size
Unit Unit Operating Circuit or Maximum Circuit
Model No. Voltage Ampacity Breaker
TTA075A 380/415 15.6 25
TTA085A 380/415 19.1 25
TTA100A 380/415 22.5 35
TTA100B 380/415 23.9 30
TTA125B 380/415 28.1 35
TTA155B 380/415 28.4 35
TTA155C 380/415 28.4 35
TTA200B 380/415 41.0 50
TTA200F 380/415 48.8 60
Table ED-2 — Electrical Characteristics — Motors — Condensing Units
Compressor Motor Condenser Fan Motor
Amps Amps
Unit RLA LRA FLA LRA
Model No. No. Phase (Ea.) (Ea.) No. Phase (Ea.) (Ea.)
TTA075A 1 3 11.2 94.9 1 1 1.6 4.0
TTA085A 1 3 13.1 100.0 1 1 2.7 9.3
TTA100A 1 3 15.8 124.0 1 1 2.7 9.3
TTA100B 2 3 9.4 63.0 1 1 2.7 9.3
TTA125B 2 3 11.3 75.0 2 1 2.7 9.3
TTA155B 2 3 11.2 94.9 2 1 1.6 4.0
TTA155C 1 3 11.2 94.9 2 1 1.6 4.0
TTA200B 2 3 15.8 124.0 2 1 2.7 9.3
TTA200F 2 3 20.0 118.0 2 1 1.9 5.8
NOTE:
1. Electrical characteristics reflect nameplate values and are calculated in accordance with UL and ARI specifications.
Table ED-3 — Electrical Characteristics — Motors — Air Handler
Standard Fan Motor Oversized Fan Motor
Unit Amps Amps
Model No. Volts Phase FLA LRA Phase FLA LRA
TWE050 380/415 3 2.9 8.2 3 1.8 21.6
TWE075 380/415 3 3.8 19.7 3 4.0 27.5
TWE100 380/415 3 4.0 27.5 3 5.3 37.5
TWE155 380/415 3 4.5 36.2 3 6.9 39.2
TWE200 380/415 3 7.6 45.0 3 9.0 65.1
