Performance data condensing unit – Trane SS-PRC003-EN User Manual
Page 34
34
SS-PRC003-EN
Table PD-21 — Gross Cooling Capacities (MBh) - Both Compressors - (I-P)
TTA100C Condensing Unit Only
OD Temp
Suction Reference Temperature °F
°F
30
35
40
45
50
55
Head press PSIG
168.5
174.3
180.4
187.0
193.9
201.2
65
Cap. Btuh/1000
100.5
110.4
120.9
131.8
143.2
154.9
OD Unit KW
6.3
6.5
6.8
7.1
7.4
7.8
Head press PSIG
192.9
198.9
205.3
212.2
219.3
226.8
75
Cap. Btuh/1000
95.7
105.3
115.5
126.0
136.9
148.0
OD Unit KW
6.9
7.1
7.4
7.8
8.1
8.5
Head press PSIG
219.7
226.1
232.9
240.1
247.6
255.4
85
Cap. Btuh/1000
90.8
100.1
109.9
120.0
130.5
141.1
OD Unit KW
7.6
7.9
8.2
8.5
8.8
9.2
Head press PSIG
249.5
256.3
263.4
270.9
278.7
286.8
95
Cap. Btuh/1000
85.9
94.9
104.2
113.9
123.9
133.9
OD Unit KW
8.4
8.7
9.0
9.3
9.7
10.1
Head press PSIG
282.0
289.1
296.6
304.4
312.5
320.8
105
Cap. Btuh/1000
80.9
89.5
98.5
107.7
117.1
126.6
OD Unit KW
9.3
9.6
9.9
10.2
10.6
11.0
Head press PSIG
317.4
324.9
332.7
340.7
349.0
357.6
115
Cap. Btuh/1000
75.8
84.1
92.6
101.3
110.2
119.1
OD Unit KW
10.4
10.6
10.9
11.3
11.6
12.0
Performance Data Calculated at 15 deg. subcooling and 15 deg. superheat.
Performance
Data
Condensing Unit
Table PD-21 — Gross Cooling Capacities (kW) - Both Compressors - (SI)
TTA100C Condensing Unit Only
OD Temp
Suction Reference Temperature °C
°C
-1.1
1.7
4.4
7.2
10.0
12.8
Head pressure (kPA)
1162
1202
1244
1289
1337
1387
18.3
Capacity (kW)
29.4
32.3
35.4
38.6
41.9
45.4
OD Unit Power (kW)
6.30
6.54
6.82
7.12
7.45
7.80
Head pressure (kPA)
1330
1372
1416
1463
1512
1564
23.9
Capacity (kW)
28.0
30.8
33.8
36.9
40.1
43.3
OD Unit Power (kW)
6.89
7.15
7.43
7.75
8.09
8.46
Head pressure (kPA)
1515
1559
1606
1656
1708
1761
29.4
Capacity (kW)
26.6
29.3
32.2
35.1
38.2
41.3
OD Unit Power (kW)
7.58
7.86
8.16
8.48
8.84
9.22
Head pressure (kPA)
1720
1767
1816
1868
1921
1977
35.0
Capacity (kW)
25.2
27.8
30.5
33.4
36.3
39.2
OD Unit Power (kW)
8.40
8.68
8.98
9.31
9.67
10.06
Head pressure (kPA)
1944
1994
2045
2099
2154
2212
40.6
Capacity (kW)
23.7
26.2
28.8
31.5
34.3
37.1
OD Unit Power (kW)
9.32
9.60
9.91
10.24
10.60
10.98
Head pressure (kPA)
2188
2240
2294
2349
2407
2466
46.1
Capacity (kW)
22.2
24.6
27.1
29.7
32.3
34.9
OD Unit Power (kW)
10.35
10.63
10.93
11.25
11.60
11.98
Performance Data Calculated at 8.3 deg. subcooling and 8.3 deg. superheat.
