12 SS-PRC003-EN
General
Data
Condensing Unit
Table GD-2— General Data
Notes:
1. Cooling Performance is rated at 95°F (35°C) ambient, 80°F (26.7°C) entering dry bulb, 67°F (19.4°C) entering wet bulb and nominal cfm listed. ARI rating cfm is 350 cfm/ton for this
product. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of
nominal cfm. Certified in accordance with the Unitary Large Equipment certification program, which is based on ARI Standard 340/360 or 365-00.
2. Condensing Unit Only Gross Cooling Capacity rated at 45°F (7.2°C) saturated suction temperature and at 95°F (35°C) ambient.
3. ARI Net Cooling Capacity is calculated with matched blower coil and 25 ft (7.2 m) of 1.375, 0.500 OD interconnecting tubing (1 5/8” suction and 5/8” liquid for TTA200F). EER and/or
SEER are rated at ARI conditions and in accordance with DOE test procedures. Integrated Part Load Value is based on ARI Standard 340/360 or 365-00. Units are rated at 80°F (26.7°C)
ambient, 80°F (26.7°C) entering dry bulb, and 67°F (19.4°C) entering wet bulb at ARI rated cfm.
4. Sound Rating shown is tested in accordance with ARI Standard 270.
5. System Data based on maximum linear length 80 ft (26.7 m) Maximum lift: suction 60 ft (18.3 m) liquid 60 ft (18.3 m) For greater lengths, refer to refrigerant piping applications
manual.
6. Outdoor Fan cfm is rated with standard air-dry coil outdoor.
7. Refrigerant (operating) charge is for condensing unit (all circuits) with matching blower coils and 25 ft (7.6 m) of interconnecting refrigerant lines.
TTA 100C TTA 125B TTA 155B TTA 155C TTA 200B TTA200F
C o o ling P e rf o rm anc e 1
Gro ss Coo ling Capacity, btu (kW)
M atched Air Handler 113,000(33.09) 134,000(39.24) 166,000(48.60) 167,000(48.90) 220,000(64.42) 220,000(64.42)
Condensing Unit Only 2 113,000(33.09) 130,000(38.06) 166,000(48.60) 167,000(48.90) 220,000(64.42) 220,000(64.42)
A RI Net Cooling Capacity 3 110,000(32.21) 130,000(38.06) 160,000(46.85) 161,000(47.14) 212,000(62.07) 212,000(62.07)
System P ower kW 10.34 12.63 16.18 16.17 21.22 20.72
Condensing Unit P ower kW 9.31 11.52 14.33 14.28 18.56 16.81
C o m press o r
Number 2 2 2 2 2 2
Type Copeland Scro ll Climatuff™Scrol Scroll Scro ll Scroll Copeland Scroll
No. M o tors (each) 1 1 1 1 1 1
M oto r HP (kW) 4.16(3.10) 5.20(3.9) 6.25(4.7) 6.25(4.7) 8.33(6.21) 8.29(6.18)
M oto r RP M 2875 2875 2875 2875 2875 2900
A R I S o und R at ing (B els) 4 8.8 8.8 8.8 8.8 8.8 9.2
S yst em D at a 5
No. Refrigerant Circuits 1 2 2 1 2 1
Suctio n Line in. (mm) OD 1.375(34.9) 1.125(28.58) 1.375(34.9) 1.625(41.3) 1.375(34.9) 1.625(41.3)
Liquid Line in. (mm) OD 0.500(12.7) 0.375(9.53) 0.500(12.7) 0.625(15.9) 0.500(12.7) 0.625(15.9)
Outdo o r C o il — T ype P late Fin Plate Fin P late Fin Plate Fin P late Fin Plate Fin
Tube Size in. (mm) OD 0.375(9.5) 0.375(9.5) 0.375(9.5) 0.375(9.5) 0.375(9.5) 0.375(9.5)
Face A rea, sq. ft (m2) 24.0(2.23) 24.0(2.23) 33.33(3.10) 33.33(3.10) 50.2(4.66) 52.9(4.91)
Rows 2 2 2 2 2 2
Fins P er Inch 20 20 20 20 18 18
Outdo o r F an T ype Propeller P ropeller Propeller P ro peller P ropeller P ro peller
No. Used 1 1 2 2 2 2
Diameter in. (mm) 28.00(711.2) 28.00(711.2) 26.00(660.4) 26.00(660.4) 28.00(711.2) 28.00(711.2)
Drive Type Direct Direct Direct Direct Direct Direct
No. Speeds 1 1 1 1 1 1
CFM 6 (m3/h) 8120(13795.0) 8120(13795.0) 9400(15970.60) 9400(15970.60) 13400(22766.60) 12100(20558)
No. M o tors 1 1 1 1 2 2
M oto r HP (kW) 0.75(.56) 0.75(.56) 0.33(.25) 0.33(.25) 0.75(.56) 0.75(.56)
M oto r RP M 925 925 925 925 925 925
R - 22 R ef rigerant C harge , lb 7 ( kg) 20.5(9.30) 23.6(10.70) 30.0(13.61) 28.0(12.70) 39.5(17.92) 41.3(18.7)-R410A
