Performance
Data
Condensing Unit
Table PD-22 — Gross Cooling Capacities (MBh) - Single Compressor - (I-P)
TTA100C Condensing Unit Only
OD Temp
Suction Reference Temperature °F
°F
30
35
40
45
50
55
Head press PSIG
138.6
141.3
144.1
147.0
150.1
153.4
65
Cap. Btuh/1000
51.3
56.5
61.9
67.7
73.7
80.1
OD Unit KW
3.1
3.2
3.3
3.4
3.5
3.6
Head press PSIG
161.5
164.4
167.3
170.4
173.7
177.2
75
Cap. Btuh/1000
48.9
54.0
59.3
64.9
70.8
77.0
OD Unit KW
3.4
3.4
3.5
3.7
3.8
3.9
Head press PSIG
186.8
189.9
193.0
196.3
199.8
203.4
85
Cap. Btuh/1000
46.5
51.4
56.6
62.1
67.8
73.8
OD Unit KW
3.7
3.7
3.8
4.0
4.1
4.2
Head press PSIG
214.8
218.1
221.4
225.0
228.6
232.3
95
Cap. Btuh/1000
44.1
48.8
53.8
59.1
64.6
70.4
OD Unit KW
4.0
4.1
4.2
4.3
4.4
4.6
Head press PSIG
245.6
249.1
252.7
256.4
260.2
264.2
105
Cap. Btuh/1000
41.6
46.1
51.0
56.1
61.4
66.8
OD Unit KW
4.4
4.5
4.6
4.7
4.9
5.0
Head press PSIG
279.4
283.0
286.8
290.7
294.7
298.9
115
Cap. Btuh/1000
39.0
43.4
48.1
52.9
58.0
63.2
OD Unit KW
4.9
5.0
5.1
5.2
5.3
5.5
Performance Data Calculated at 15 deg. subcooling and 15 deg. superheat.
Table PD-22 — Gross Cooling Capacities (kW) - Single Compressor - (SI)
TTA100C Condensing Unit Only
OD Temp
Suction Reference Temperature °C
°C
-1.1
1.7
4.4
7.2
10.0
12.8
Head pressure (kPA)
956
974
994
1014
1035
1057
18.3
Capacity (kW)
15.0
16.5
18.1
19.8
21.6
23.4
OD Unit Power (kW)
3.13
3.21
3.30
3.39
3.50
3.62
Head pressure (kPA)
1114
1133
1154
1175
1198
1222
23.9
Capacity (kW)
14.3
15.8
17.4
19.0
20.7
22.6
OD Unit Power (kW)
3.36
3.45
3.54
3.65
3.77
3.89
Head pressure (kPA)
1288
1309
1331
1354
1378
1402
29.4
Capacity (kW)
13.6
15.1
16.6
18.2
19.9
21.6
OD Unit Power (kW)
3.65
3.74
3.85
3.96
4.08
4.21
Head pressure (kPA)
1481
1504
1527
1551
1576
1602
35.0
Capacity (kW)
12.9
14.3
15.8
17.3
18.9
20.6
OD Unit Power (kW)
4.01
4.10
4.20
4.32
4.44
4.58
Head pressure (kPA)
1694
1717
1742
1768
1794
1821
40.6
Capacity (kW)
12.2
13.5
14.9
16.4
18.0
19.6
OD Unit Power (kW)
4.42
4.51
4.62
4.73
4.86
5.00
Head pressure (kPA)
1926
1951
1977
2004
2032
2061
46.1
Capacity (kW)
11.4
12.7
14.1
15.5
17.0
18.5
OD Unit Power (kW)
4.89
4.98
5.08
5.20
5.32
5.46
Performance Data Calculated at 8.3 deg. subcooling and 8.3 deg. superheat.
