6-89
ASGG Analog Sync on Green Gating
Classification: (Obsolete) Format parameter setting
Command Syntax: ASGG
Limits:
0 = OFF
1 = ON
Query Syntax: ASGG?
Query Response:
Description: The ASGG command enables and disables adding composite
sync to the green analog video outputs when analog sync is
selected (see SSST command) and an analog video signal is being
generated (see AVST command). The ASGG? query returns the
current setting of ASGG.
S e e t h e A S S G c o m m a n d d e s c r i p t i o n f o r i n f o r m a t i o n o n
simultaneously controlling red, green and green sync gating.
Other Required Cmds: The FMTU command instructs the generator to use the new
setting. The ALLU command updates hardware to the new setting
and redraws the test image.
Example: A S G G 1 / / E n a b l e c o m p s y n c o n g r e e n i n
/ / b u f f e r
F M T U / / U p d a t e h a r d w a r e t o c u r r e n t
/ / b u f f e r c o n t e n t s
ASRG Analog Sync on Red Gating
Classification: (Obsolete) Format parameter setting
Command Syntax: ASRG
Limits:
0 = OFF
1 = ON
Query Syntax: ASRG?
Query Response:
Description: The ASRG command enables and disables adding composite
sync to the red analog video outputs when analog sync is selected
(see SSST command) and an analog video signal is being generated
(see AVST command). The ASRG? query returns the current
setting of ASRG.
S e e t h e A S S G c o m m a n d d e s c r i p t i o n f o r i n f o r m a t i o n o n
simultaneously controlling red, green and red sync gating.
Other Required Cmds: The FMTU command instructs the generator to use the new
setting. The ALLU command updates hardware to the new setting
and redraws the test image.
Example: A S R G 1 / / E n a b l e c o m p s y n c o n r e d i n
/ / b u f f e r
F M T U / / U p d a t e h a r d w a r e t o c u r r e n t
/ / b u f f e r c o n t e n t s
