1. Turn the printer off and unplug the power cable.
2. Unplug the printer interface cable.
Caution! The printer weighs 160 lbs. (72 kg).
Use at least two people to lift the printer.
Use proper lifting techniques.
3. Unpack the High Capacity Feeder (HCF) and remove any shipping materials.
4. To prevent toner spillage and to reduce the weight of the printer, making it easier to
place on the feeder, open the top cover and remove the image drums/toner cartridges,
covering them to protect them from light while they are outside the printer.
5. Move the printer aside.
6. Move the HCF into position. Note the location of the pins and connector.
Pins
Connector
7. If you are also installing an Auxiliary Paper Tray, place the tray on top of the HCF,
aligning the holes and plug in the bottom of the tray with the pins and connector on the
HCF.
