Installing the OkiLAN
®
6020e Print Server
1. Turn off the printer.
2. Attach the OkiLAN 6020e to the parallel port on the printer and secure it with the wire
clips.
3. Plug the power adapter wire into the power jack on the OkiLAN 6020e.
4. Plug the power adapter into a 120-volt wall outlet.
5. Attach an Ethernet cable to the 10/100 BaseT port on the back of the OkiLAN 6020e.
6. Attach the other end of the cable to the network.
7. Turn the printer on.
The red and green lights on the OkiLAN 6020e blink during the self-test. When the self-
test completes successfully, the red indicator goes off and the green indicator stays on.
8. Press the test button on the front of the OkiLAN 6020e to print a configuration sheet.
You will need the information from this sheet when setting up your printer on the
network.
Note: The content of the configuration sheet will vary depending on your printer and
system setup.
Hard Disk Drive, OKI P/N 70037301
