Step 1: Install the Tray(s)
Back
Right
(MP Tray)
Left
(Straight-Through
Paper Path)
Front
1. Unpack the auxiliary tray(s) and remove the shipping materials.
2. Turn the printer off and unplug the power cord.
3. Remove the interface cable.
4. Move the printer aside.
5. Move the auxiliary tray into position (paper tray facing front). Note the location of the pins
and connector on the tray.
Pins
Connector
6. If you are installing two trays, place the first tray on top of the second one, aligning the
holes and plug in the bottom of the upper tray with the pins and socket on the lower tray.
