5... H YPER C OMM ™ C OMMUNICATIONS
U SING THE OMP-MODL 5-5
Baud:
Specify the baud rate rate that will be used to communicate between
the PC and the local modem. Set this baud rate per the following
table:
FYI: The remote modem (at the logger) will automatically
adapt to the baud rate of the calling modem.
Redial:
If this box is checked, HyperWare will automatically make another
attempt to call the logger if the first attempt fails for any reason.
The time specified in the edit box is a delay time to wait before
attempting the next call.
Figure 5... -3: Serial Communications setup dialog box (Modem mode)
Local Modem Capability Set Dialog Box Baud To:
1200 baud 1200 baud
2400 baud 2400 baud
9600 or faster baud 19,200 baud
Table 5... -1: Local modem settings
