3... I NTERFACE M ODULES
U SING THE OMP-MODL 3-57
MLIM-5-144; PCMCIA AND 14.4K B AUD M ODEM M ODULE
Overview:
The MLIM-5-144 module provides PCMCIA memory card support as
discussed in the MLIM-5 section and also provides 1200, 2400, 4800, 9600,
and 14400 Baud telephone modem communications capability. Installation
of this module will allow the full complement of serial communications/
control of the OMP-MODL from a remotely located PC equipped with a
modem. Additionally, loggers equipped with a modem can utilize the Pager
Alarm Output feature from within HyperWare (see Appendix A).
The MM-14.4 is a low power modem, drawing approximately 125mA during
operation (off-hook) and 0 mA while quiescent (on-hook).
Installation / Operation:
The MM-14.4 is installed and configured identically to the MLIM-5-2400.
Refer to the MLIM-5-2400 installation and configuration instructions in the
previous section for details.
Additional information on the setup and configuration of the modem located
at the PC is provided in Appendix K.
