3... I
NTERFACE
M
ODULES
U
SING THE
OMP-MODL
3-5
I
NTERFACE
M
ODULE
O
PERATIONAL
I
NSTRUCTIONS
:
Each Interface Module has specific characteristics and instructions for set-up and
use that are unique to that particular module. These instructions are included in
following sections or provided with the Interface Module at the time of purchase. As
Interface Modules are added to a User’s OMP-MODL, the instruction sheets
provided should be added to this section of the manual.
The instructions for most Interface Modules include both hardware and software
details. Software instructions will commonly be referenced from other sections of
this manual such as in the chapter on HyperComm for the modem modules and the
chapter on HyperNet programming for analog and digital Interface Modules.
Instruction sheets for the following Interface Modules are currently included in this
section:
♦
ML-BATT; Battery Pack Module
♦
ML-DISP; Display and User Interface Module
♦
MLIM-1; Analog (thermocouple, Vdc and Adc Interface
Module (Configuration shared with MLAD-1 Module)
♦
MLIM-2; Event, Frequency, Count Interface Module
♦
MLIM-4; RTD, Thermistor, and Resistance Module
♦
MLIM-8; Digital Interface Module (8 channel digital I/O)
♦
MLIM-5 PCMCIA Memory Card Interface Module
♦
MLIM-5 PCMCIA Memory Card Interface Module with
2400B modem
♦
MLIM-5 PCMCIA Memory Card Interface Module with
14,400B modem
