11.. . A
PPENDIX
A: M
ASTER
I
CON
R
EFERENCE
U
SING THE
OMP-MODL
11-77
NOT
(I
NVERTER
) L
OGIC
F
UNCTION
I
CON
The NOT icon inverts the signal as it passes through. When the Input isTrue the Output
is False. When the Input is False, the Output is True.
INPUTS:
Data/Logic Signal: Logic (True/False) type.
Update Clock:
None
Enable:
None
OUTPUTS:
Output Signal:
Logic type.
ICON CONFIGURATION DIALOG BOX:
CONFIGURATION OPTIONS:
Icon Name: Specify the label for the icon. This name will show directly under the icon
within the Program Net.
Output True when ________ is False:
HyperNet completes this functional
statement using the name of the Output from the icon that is connected to
this NOT (inverting) icon’s Inputs.
Output Name:
Specify the label for the Output. This name will show directly
under the Output terminal within the Program Net.
