5... H YPER C OMM ™ C OMMUNICATIONS
U SING THE OMP-MODL 5-4
HyperComm Connection via Modem:
Launch HyperWare and after the opening screen, the H YPER C OMM window
will be displayed. Move the cursor over the graphic DB-25 type connector
(center of the screen on the cable) and double-click to bring up the S
ERIAL
C OMMUNICATIONS dialog box (Figure 5... -2).
Click on the U SE M ODEM check box under M ODEM C ONTROL and the dialog
will change slightly (Figure 5... -3) to enable editing of parameters in the
M
ODEM C ONTROL section. Edit the various parameters within the M ODEM
S ERIAL C OMMUNICATIONS dialog box per the following guidelines:
Port:
Specify the P ORT using the pull-down list box under the P ORT
P ARAMETER S ECTION . Select the port to which the modem is
connected.
TIP: If the port number to which the modem is
connected is unkown, select one of the ports then
attempt to connect (see following). If unsuccessful,
change the selected Port and try again.
