19
Before You Start Playing
1. Insert the pedal cable into the Pedal connector on the
rear bottom panel of the RM-700.
1. As shown in the diagram, connect the speaker cable
leading from the speaker box of the stand to the speaker
connector located on the rear bottom panel of the RM-
700.
Push the speaker cable in until it clicks into position.
1. Insert the included power cord into the AC inlet on the
rear bottom panel of the RM-700, and then plug it into an
electrical outlet.
Be sure to use the supplied power cord.
1. Grasping the music rest with both hands, lift it toward
you until its in the upright position.
2. Use the support on the back of the music rest to keep the
stand in place.
The angle of the music rest can be set to any of three positions.
1. Raise the support located on the back of the music rest,
then gently fold down the music rest.
You can use the holders to hold pages in place.
When not using the holders, leave them folded down.
Connect the Pedal Cable
Connect the Speaker Cable
Connect the Power Cord
Pedal cable
Speaker cable
Power cord
To
AC outlet
Setting Up the Music Rest
Folding Down the Music Rest
Using the Music Holders
1
2
Push
Push
