Other Settings
Settings for transmitted messages
Here’s how to specify the MIDI messages that will be transmitted
when a [USER/MIDI] coupler is on.
1. From the main screen, press the [Select/Menu] knob.
2. Turn the [Select/Menu] knob to select “5 USER/MIDI
Coupler.”
fig.LCD006.eps
3. Press the [Select/Menu] knob to access the “USER/MIDI”
screen.
4. Turn the [Select/Menu] knob to move the cursor to the
top position, and then turn the [Value/Exit Menu] knob
to select the tablet that you want to change the settings.
fig.LCD093.eps
5. Turn the [Select/Menu] knob to select item, and then turn
the [Value/Exit Menu] knob to change the settings.
fig.LCD074.eps
6. Press the [Value/Exit Menu] knob twice to return to the
main screen.
Indication Tablet name
MAN-I A MAN I (lower) [USER MIDI A]
MAN-I B MAN I (lower) [USER MIDI B]
MAN-II A MAN II (upper) [USER MIDI A]
MAN-II B MAN II (upper) [USER MIDI B]
PEDAL A PEDAL (pedalboard) [USER MIDI A]
PEDAL B PEDAL (pedalboard) [USER MIDI B]
Indication Explanation Range
Name Select by sound name Name of sound
PC Number Program change number OFF, 1–128
Bank MSB Bank select MSB OFF, 0–127
Bank LSB Bank select LSB OFF, 0–127
Volume Specifies the volume OFF, 0–127
Octave Specifies the octave (pitch) -2–+2
Reverb Specifies the depth of reverb OFF, 1–127
Chorus Specifies the depth of chorus OFF, 1–127
Velocity
Velocity value
KBD:
The keyboard’s velocity will be used
EXP:
The expression pedal’s position will be used
2–127:
The specified value will be used as the velocity
Expression Expression Pedal OFF, ON
Indication Explanation Range
Selecting sounds on your external MIDI device
How sound names are displayed
If an MX-200 or a GM2 compatible sound module is connected,
you can set “Tone Name” to the model of sound module you’re
using (p. 72), so that the “USER/MIDI” screen’s “Name” field will
show the names of the sounds, allowing you to choose sounds
by name.
Using the keyboard to select
Even when the “USER/MIDI” screen is not shown, you can use
the following method to select sounds on your external MIDI
device.
1. Turn on the desired [USER/MIDI] coupler.
2. Hold down the [SET] piston and play a note on the
keyboard and the pedalboard.
The [USER/MIDI] coupler will blink.
The program change corresponding to the note you played
will be transmitted, and the sound selection on your MIDI
device will change.
Each note of the keyboards corresponds to the following
program changes.
Keyboard Tone name Program change
Lower keyboard C2–C7 1–61
Upper keyboard C2–C7 62–122
Pedalboard C2–F2 123–128
