Alteon OS Command Reference
38 „ First-Time Configuration BMD00007, November 2007
Setup Part 3: VLANs
If you chose to skip VLANs configuration back in Part 1, skip to “Setup Part 4: IP Configura-
tion” on page 39 .
1. Select the VLAN to configure, or skip VLAN configuration at the prompt:
If you wish to change settings for individual VLANs, enter the number of the VLAN you wish
to configure. To skip VLAN configuration, press without typing a VLAN number and
go to
“Setup Part 4: IP Configuration” on page 39 .
2. Enter the new VLAN name at the prompt:
Entering a new VLAN name is optional. To use the pending new VLAN name, press .
3. Enter the VLAN port numbers:
Enter each port, by port number or port alias, and confirm placement of the port into this
VLAN. When you are finished adding ports to this VLAN, press without specifying
any port.
4. Configure Spanning Tree Group membership for the VLAN:
5. The system prompts you to configure the next VLAN:
VLAN Config:
Enter VLAN number from 2 to 4094, NULL at end:
Current VLAN name: VLAN 2
Enter new VLAN name:
Define Ports in VLAN:
Current VLAN 2: empty
Enter ports one per line, NULL at end:
Spanning Tree Group membership:
Current Spanning Tree Group index: 1
Enter new Spanning Tree Group index [1-127]:
VLAN Config:
Enter VLAN number from 2 to 4094, NULL at end:
