Alteon OS Command Reference
The Configuration Menu „ 325 BMD00007, November 2007
/cfg/pmirr/monport
Port-Mirroring Configuration
[Port EXT1 Menu]
add - Add "Mirrored" port
rem - Rem "Mirrored" port
delete - Delete this "Monitor" port
cur - Display current Port-based Port Mirroring configuration
Table 6-116 Port Mirroring Monitor Port Menu Options (/cfg/pmirr/monport)
Command Syntax and Usage
add
Adds the port to be mirrored. This command also allows you to enter the direction of the traffic. It
is necessary to specify the direction because:
If the source port of the frame matches the mirrored port and the mirrored direction is ingress or
both (ingress and egress), the frame is sent to the mirrored port.
If the destination port of the frame matches the mirrored port and the mirrored direction is egress or
both, the frame is sent to the monitoring port.
rem
Removes the mirrored port.
delete
Deletes this monitor port.
cur
Displays the current settings of the monitoring port.
