Alteon OS Command Reference
The Configuration Menu „ 233 BMD00007, November 2007
/cfg/l2/stg < STP group number>/brg
Spanning Tree Bridge Configuration
Spanning Tree bridge parameters affect the global STG operation of the switch. STG bridge
parameters include:
„ Bridge priority
„
Bridge hello time
„ Bridge maximum age
„ Forwarding delay
„
Bridge aging time
[Bridge Spanning Tree Menu]
prior - Set bridge Priority [0-65535]
hello - Set bridge Hello Time [1-10 secs]
mxage - Set bridge Max Age (6-40 secs)
fwd - Set bridge Forward Delay (4-30 secs)
aging - Set bridge Aging Time (1-65535 secs, 0 to disable)
cur - Display current bridge parameters
Table 6-38 Spanning Tree Bridge Menu Options (/cfg/l2/stg/brg)
Command Syntax and Usage
prior
Configures the bridge priority. The bridge priority parameter controls which bridge on the network
is the STG root bridge. To make this switch the root bridge, configure the bridge priority lower
than all other switches and bridges on your network. The lower the value, the higher the bridge pri-
ority. The range is 0 to 65535, and the default is 32768.
RSTP/MSTP: The range is 0 to 61440, in steps of 4096 (0, 4096, 8192...), and the default
is 32768.
hello
Configures the bridge hello time.The hello time specifies how often the root bridge transmits a
configuration bridge protocol data unit (BPDU). Any bridge that is not the root bridge uses the root
bridge hello value. The range is 1 to 10 seconds, and the default is 2 seconds.
This command does not apply to MSTP (see CIST on page 227 ).
mxage
Configures the bridge maximum age. The maximum age parameter specifies the maximum time
the bridge waits without receiving a configuration bridge protocol data unit before it re configures
the STG network. The range is 6 to 40 seconds, and the default is 20 seconds.
This command does not apply to MSTP (see CIST on page 227 ).
