Alteon OS Command Reference
The Configuration Menu „ 315 BMD00007, November 2007
/cfg/acl/acl < ACL number>/ipv4
IP version 4 Filtering Configuration
This menu allows you to define IPv4 matching criteria for an ACL.
reset
Resets Ethernet parameters for the ACL to their default values.
cur
Displays the current Ethernet parameters for the ACL.
[Filtering IPv4 Menu]
sip - Set to filter on source IP address
dip - Set to filter on destination IP address
proto - Set to filter on prototype
tos - Set to filter on TOS
reset - Reset all fields
cur - Display current parameters
Table 6-106 IP version 4 Filtering Menu Options (/cfg/acl/acl x/ipv4)
Command Syntax and Usage
sip
Defines a source IP address for the ACL. If defined, traffic with this source IP address will match
this ACL. Specify an IP address in dotted decimal notation.
dip
Defines a destination IP address for the ACL. If defined, traffic with this destination IP address
will match this ACL.
proto <0-255>
Defines an IP protocol for the ACL. If defined, traffic from the specified protocol matches this fil-
ter. Specify the protocol number. Listed below are some of the well-known protocols.
Number Name
1 icmp
2 igmp
6 tcp
17 udp
89 ospf
112 vrrp
Table 6-105 Ethernet Filtering Menu Options (/cfg/acl/acl x/ethernet)
Command Syntax and Usage
