Appendix B BIP external cable pin assignments
312755-G Rev 00
lists the pin assignments for the J5 standalone office alarm connector.
Table 8 J5 standalone office alarm connector pin assignments
Pin
Signal
Description
1
Critical alarm—Visual (NC)
Visual alarm contact
2
Major alarm—Visual (NC)
Visual alarm contact
3
Minor alarm—Visual (NC
Visual alarm contact
4
Critical alarm—Audible (NC)
Audible alarm contact
5
Major alarm—Audible (NC)
Audible alarm contact
6
Minor alarm—Audible (NC)
Audible alarm contact
7
External alarm—(NC)
External alarm contact
10
Critical alarm—Visual (COM)
Visual alarm contact
11
Major alarm—Visual (COM)
Visual alarm contact
12
Minor alarm—Visual (COM
Visual alarm contact
13
Critical alarm—Audible (COM)
Audible alarm contact
14
Major alarm—Audible (COM)
Audible alarm contact
15
Minor alarm—Audible (COM)
Audible alarm contact
16
External alarm—(COM)
External alarm contact
19
Critical alarm—Visual (NO)
Visual alarm contact
20
Major alarm—Visual (NO)
Visual alarm contact
21
Minor alarm—Visual (NO
Visual alarm contact
22
Critical alarm—Audible (NO)
Audible alarm contact
23
Major alarm—Audible (NO)
Audible alarm contact
24
Minor alarm—Audible (NO)
Audible alarm contact
25
External alarm—(NO)
External alarm contact
