Figure 19, Location of power supplies, Figure 19 location of power supplies – Nortel Networks 8010co User Manual
Page 40
40
Chapter 2 Installation
312755-G Rev 00
2
Locate the power supplies (
).
With the bezel removed, you can see the power supplies. The chassis can
contain up to three power supplies. (Power supplies reside in bay 1, bay 2, and
bay 3, viewed left to right from the front of the chassis.)
Figure 19 Location of power supplies
Fail
Pass
Fail
Pass
+DC
-DC
+DC
-DC
+DC
-DC
1 = Power supply (bay 1)
2 = Power supply (bay 2)
3 = Power supply (bay 3)
1
2
3
10423FA
