Page 58
58
Chapter 2 Installation
312755-G Rev 00
7
Connect the remaining -48 VDC input returns as required (
).
shows the BIP with all power cables and returns installed.
Figure 40 Connecting the A/B input feed returns (2 of 2)
8
Go to the next section,
.
Note: Be sure to properly support the cables with cable ties to avoid
undue stress to the power terminal block.
3 2
PS (+)
Lower Shelf
PS (+)
Upper Shelf
PS (-)
Lower Shelf
PS (-)
Upper Shelf
A/B Input Feed
Returns
– 48 VDC
A/B Input Feeds
1 3 2 1
3 2 1 3 2 1
A
2
A
1
B
1
B
2
-48 VDC Feeds
10409FA
