Chapter 4 Block Reference
© National Instruments Corporation 4-15 FieldPoint FP-3000 User Manual
Supported FieldPoint Modules and Channels
The FP-3000 supports a wide variety of I/O channels, each with different
types of configuration information. For example, a thermocouple channel
includes parameters for thermocouple type and has ranges for different
temperatures; a current loop channel includes parameters for filter
frequency and has a different group of available ranges to chose from.
Because of these differences in parameters, the FP-3000 has a block
specific to each type of channel it supports. For example, to use a
thermocouple connected to an I/O channel on an FP-TC-120 module, the
FP-3000 provides a FP-TC-120 AI Block. This block is a standard Analog
Input block augmented with parameters specific to the thermocouple
channel on the FP-TC-120.
The FP-3000 does not support all FieldPoint I/O modules. In particular, the
counter module is one module that is often requested, but not supported.
Support for other modules might be added in later firmware revisions.
The following table shows the function block that corresponds to each
supported FieldPoint I/O module.
Table 4-6. FieldPoint Modules
Channel Type
Supported
Module Block Type
Analog Input FP-AI-100 Fp Ai 100
FP-AI-110 Fp Ai 110
FP-AI-111 Ap Ai 111
FP-TC-120 Fp Tc 120
Fp Tc 120 C (cold junction
compensation)
FP-RTD-122 Fp Rtd 122
Analog Output FP-AO-200 Fp Ao 200
FP-AO-210 Fp Ao 210
FP-PWM-520 Fp Pwm 520
